PIONEER HIFI POWER AMPLIFIER FOR CAR, GMD9605

Description

PIONEER HIFI POWER AMPLIFIER FOR CAR, GMD9605.

The Pioneer GM-D9605 is a compact 5-channel Class D car amplifier delivering up to 2000W max power (75W RMS x 4 + 600W RMS x 1 sub). It is ideal for upgrading full-system audio in limited spaces, offering high-efficiency, flexible crossover networks, and a included wired bass boost remote.

Features:

• Class-FD Design: This proprietary Class-D design offers higher efficiency and lower heat generation compared to traditional Class-AB amplifiers, allowing for a smaller chassis.
• Wired Bass Boost Remote: Includes a remote knob to adjust the subwoofer level from 0 to 18 dB directly from the driver’s seat.
  Variable Crossovers: Features adjustable high-pass and low-pass filters (40-500 Hz) to fine-tune sound for specific speaker and subwoofer characteristics.
  Auto Turn-on: Uses signal-sensing speaker-level inputs to automatically power the amp on/off when the factory radio is used, eliminating the need for a separate remote turn-on wire.
  Block Terminals: Large, secure terminals minimize resistance and simplify clean wire installation.

Power Specifications:

• 4-Ohm RMS Power: 75 watts x 4 channels (front/rear) + 350 watts x 1 (subwoofer).
  2-Ohm RMS Power: 100 watts x 4 channels + 600 watts x 1 (subwoofer).
  Bridged Mode: 200 watts x 2 channels (at 4 ohms) + 600 watts x 1 (subwoofer at 2 ohms).
  Total Max Power: 2,000 watts.
